TS16 vs TS20 : Comparison Table to Help You Make Your Decision
Are you using a TS16 and wondering if upgrading is worth it? This point-by-point comparison will help you see things more clearly.
The Leica TS16 has been the benchmark in robotic total stations for surveyors in Quebec for years. Reliable, precise, and versatile, it has proven itself on countless job sites. With the arrival of the TS20, the question is inevitable: is now the right time to upgrade?
To help you make an informed decision, we’ve compared the two instruments based on the criteria that matter most in day-to-day use.
CRITERION | LEICA TS16 | LEICA TS20 |
Protection | IP55 | IP66 (world’s first robotic total station) |
Artificial Intelligence | None | Integrated NPU : AI-ATR, AI-Detect, AI-Follow |
Target Recognition | ATRplus (self-learning) | AI-powered ATR + prism type detection |
Motors | Standard motorized | Direct-drive BLDC silent, < 2s face change |
EDM | Standard | High frequency up to 25 Hz |
Camera | 5 MP | 20 MP + fast panoramas + live video |
Operating System | Windows CE | Linux (Captivate v10) |
Screen | Touchscreen | Multi-touch with zoom/scroll |
Connectivity | WiFi/3.5G via controller | Dual eSIM + WLAN + Ethernet + built-in USB-C |
Data Transfer | Standard USB | USB-C drag & drop + real-time cloud |
Anti-theft Protection | LOC8 (separate accessory) | Built-in GeoCloud Protect (tracking + remote lock) |
AP20 Compatibility | Yes (Captivate v7+) | Yes + AI-Follow for predictive tracking |
AutoHeight | Yes (optional) | Yes (enhanced, built-in) |
AI Scalability | No | Yes — updates via NPU |
Our Analysis
The TS16 remains an excellent, proven instrument. If your fleet is relatively recent and your needs are stable, it will continue to serve you reliably.
NEED PERSONALIZED GUIDANCE ?Our ABTECH Representatives understand your field reality. Talk with them to assess whether the TS20 meets your specific needs.Contact your ABTECH representative → abtech.cc |
